Frigidaire Dryer No Heat? Here's Why You Need Heating Element 5308019313

Your Frigidaire dryer just ran a full 60-minute cycle and your clothes are somehow wetter than when you started. Sound familiar? That's the heating element calling it quits, and we've got the fix.

What's Actually Going On

When your Frigidaire electric dryer runs a full cycle but everything comes out cold and damp, the motor and drum are doing their jobs, but the heat source is completely dead. The most likely culprit is a burned-out heating element, part number 5308019313. This element is a coiled resistance wire strung inside a metal frame. It glows red-hot, heats the air moving through the drum, and dries your clothes. When even one spot on that coil breaks or burns out, the whole thing stops producing heat. Zero. Zilch. Your dryer is basically a very expensive spinning room-temperature box at that point.

Now, before you start buying parts, rule out the easy stuff first. Check that your dryer is actually plugged into a 240V outlet, that both legs of the breaker are live (flip the breaker fully off, then back on, a half-tripped breaker lets the drum spin but kills the heat), and that your exhaust vent isn't clogged. A blocked vent trips the thermal fuse and shuts down heat as a safety response. If you've done all that and you're still getting Frigidaire dryer no heat, you're almost certainly looking at a bad element.

To confirm before you buy anything, unplug the dryer, remove the back panel, locate the heating element housing, disconnect the wires from the element terminals, and test across them with a multimeter set to continuity. A good element beeps. No beep means the coil is broken and you need 5308019313 in your hands ASAP.

The Fix

Here's how to swap in the new heating element. Budget about 45 minutes and grab a #2 Phillips, a 5/16" nut driver, and a multimeter.

1. Unplug the dryer. Seriously, don't skip this. Electric dryers run on 240V and they will absolutely ruin your day.
2. Pull the dryer away from the wall and remove the back access panel, usually 8-10 screws around the perimeter.
3. Locate the heating element housing in the lower-right section of the back. It's a can-shaped metal enclosure with two or three wires plugged into it.
4. Photograph your wiring before you disconnect anything. Snap a pic on your phone, you'll thank yourself later.
5. Disconnect the wires from the element terminals and the thermal limiter/thermostat attached to the housing (these clip right off).
6. Remove the mounting screws holding the housing in place (typically two screws) and slide the old assembly out.
7. Transfer the thermal limiter and thermostat from the old housing to the new 5308019313 assembly, they bolt right on.
8. Slide the new element in, reinstall the mounting screws, and reconnect your wiring using your photo as a guide.
9. Replace the back panel, plug the dryer in, and run a test cycle with a damp towel.

If it's blowing hot air within the first two minutes of a timed dry cycle, bro, you nailed it.

When to Call YAP vs DIY

DIY it: If you're comfortable using a multimeter and a screwdriver and confirmed the element is the issue, this is a very beginner-friendly repair. Heating element 5308019313 is one of the most-replaced parts we stock for Frigidaire dryer not drying complaints, you've got this.

Call YAP: If your new element works for a day and then goes out again, something is creating excess heat and killing elements early, a clogged vent, a faulty cycling thermostat, or a bad thermal limiter. That's when you call us at 405-876-8100 and we'll walk you through the full diagnosis before you spend another dime.

Swing by the Piedmont shop or text us at 405-876-8100, we stock 5308019313 and we'll make sure you grab everything you need in one trip.
