Frigidaire Freezer Not Freezing? Your Start Relay Is Probably Dead (Part 5304491941)

Your Frigidaire upright freezer is humming along like everything's fine, but your ice cream is soup and your meat feels soft, and the temp won't budge below 30°F. That's not a "freezer running" problem. That's a "freezer running but not actually doing its job" problem, and bro, there's a big difference.

What's Actually Going On

Here's the thing: when your Frigidaire freezer not freezing situation shows up like this, motor running, lights on, compressor seemingly alive, most people assume the worst. "It's the compressor. I need a new freezer." Slow down. Before you drag that thing to the curb, you need to check the compressor start relay, because nine times out of ten, that's the actual villain here.

The start relay is a small, cheap component that plugs directly onto the compressor. Its whole job is to give the compressor that initial electrical kick it needs to start a cooling cycle. When the relay fails, and they do fail, especially on older Frigidaire units, the compressor either won't start at all, or it tries to start, stumbles, and gives up. The result? The fan keeps running (so the freezer sounds fine), but no real refrigeration is happening. Food stays soft. Temps hover stubbornly around 28 to 32°F.

The dead giveaway is the rattle test. Pull the start relay off the compressor terminals and give it a shake next to your ear. If you hear something rattling around inside like a broken piece of gravel, that relay is toast. A good relay is silent. Simple as that.

The Fix

Good news: this is one of the most beginner-friendly repairs in the appliance world. Here's how to knock it out.

1. Unplug the freezer. Non-negotiable. Always.
2. Pull the freezer away from the wall and remove the rear access panel (usually just a few screws).
3. Locate the compressor, it's the big, black, dome-shaped unit at the bottom.
4. The start relay is the small component plugged into the side of the compressor. Grab it and pull it straight off the terminals.
5. Do the rattle test. Rattles = dead. Silence = potentially something else, but still worth swapping it out.
6. Plug in your new 5304491941 start relay. It clicks right onto the same terminals, no wiring, no splicing, no drama.
7. Reinstall the panel, push the freezer back, plug it in, and give it 4 to 6 hours to pull temp down.

The 5304491941 is the correct OEM start relay for a wide range of Frigidaire upright freezers, and we stock it here at YAP in Piedmont. Price is way friendlier than a service call, trust me. A start relay replacement is exactly the kind of fix that makes you feel like a genius for $15, $25 instead of paying someone $150 to do it for you.

When to Call YAP vs. DIY

DIY this one. If your rattle test confirms a bad relay and your freezer is otherwise in decent shape, this is a confident beginner repair. Unplug, swap the part, done.

Call us if the new relay doesn't fix it after a full cool-down cycle, at that point the compressor itself may be failing, refrigerant could be low, or you've got an electrical issue that needs a tech. We can help you figure out your next move without guessing.

Don't overthink the Frigidaire freezer not freezing problem until you've ruled out the cheapest part first. The 5304491941 start relay is in stock and ready to go, swing by the Piedmont shop or call/text us at 405-876-8100 and we'll have it waiting at the counter for you.
